Continuous Drying 10000kg/H SUS304 Milk Powder Spray Dryer
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | XIANDAO |
| Certification: | CE / UL / SGS / EAC / CR – TU |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case |
| Delivery Time: | 8~18 WEEKS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 SETS PER MONTH |
|
Detail Information |
|||
| Product Name: | SUS304 Milk Powder Production Line | Material: | SUS316/SUS304/ CARBON STEEL, ETC |
|---|---|---|---|
| Heating Source: | Steam / Electrical / Natural Gas / Diesel / Etc. | Capacity: | 10-10000kg Per Hour |
| Water Evaporation: | 5-5000kg Per Hour | Temp: | 120-600°C |
| Drying Pattern: | Continuous Drying | Control: | Rotary Atomizer |
| Highlight: | SUS304 milk powder production line,10000kg milk powder spray dryer,SUS304 milk powder spray dryer |
||
Product Description
SUS304 Milk Powder Production Line / special spray dryer for Milk Powder Production
General Descriptions
Refer to milk powder, there are two types: one is full-fat milk powder, the other is skimmed milk powder, and there are so much differences between these two kinds of milk powder. Normally , our design is based on user’s request.
Product details
| Material: | SUS316/SUS304/ CARBON STEEL ,ETC | Heating Source: | Steam / Electrical / Natural Gas / Diesel / Etc. |
| Capacity: | 10-10000kg Per Hour | Water Evaporation: | 5-5000kg Per Hour |
| Temp: | 120-600'C | Drying pattern: | Continuous Drying |
| Document: | FAT/ IQ / OQ / PQ | Certificate: | CE / UL /CU-TR |
| Control: | HMI & BUTTON | Atomizing mode: | Rotary atomizer |
| High Light: | Food dryer machine, special spray dryer for milk powder, spray drying plant | ||
Production line overview
The milk production line can be applied to the production of various liquid milks, such as grassland fresh milk, flavored milk, yogurt drinks, yogurt and lactic acid bacteria drinks. This small production line (300L/h-1000l/H) is characterized by reasonable design, compact structure, beautiful layout, effective energy saving, and simple operation and maintenance. It is especially suitable for new product development equipment of small production enterprises and experimental practice equipment of scientific research institutes, colleges and universities.
Processing description
The line is mainly composed of water & powder mixer, double segment plate-type heat exchanger, high speed mixing tank, plate sterilizer (95ºC, 300S, 125ºC, 15S), heat preservation tank, homogenizer (25MPa), fermentation tank, high position tank, rotor pump and self-priming pump,spray drying ,sifter and so on.
Detailed processing introduction
1. Water Treatment section:
Sand filter, Activated carbon filter, Water softener, Precision filter, Reverser osmosis filter, Electrical control system, UV filter, Water storage tank
2. Milk Receiving Section
Out door storage tank, Milk weight tank, Milk receiving tank, Temporary storage tank, Duplex filter, Milk Separator, Plate heat exchanger, Milk Storage Tank
3. Mixing Section
Hot water tank, Plate heat exchanger, Square high speed emulsification tank,
Water-powder mixer, Mixing tank, Oilcan, Pipeline flow meter, Duplex Filer, Homogenizer
4. Concentration Section
Three-efficiency concentrating tower, Balance tank, Double sealed circulating pump, The single sealing health pump, Cooling water pump, Self-priming pump, Water ring vacuum pump, Cooling tower
5. Drying section
Concentrated milk tank, High-pressure pump, Spray-drying tower, Fluidized bed, Electric sieve, Milk powder groove
6. Packing Section
7. CIP Cleaning Section
Acid tank, Alkali tank, Hot water tank, Pleat heat exchanger, Cleaning pump
8. Compressor
Air compressor, Air filter, Air dryer, Air storage tank
9. Boiler section
Horizontal boile, Steam tank
10. Refrigeration section
Refrigeration machine, Ice water tank, Cooling tower, Ice water pump, Pipeline centrifugal pump
All the equipments and pipelines touching materials are made of stainless steel SUS304.
As to let customer control every data easily , normally , our control system is made with PLC
+HMI .and main electrical components are from international bran
The automatic control system of production line adopts German SPAIRAX SARCO pressure release valve, regulating valve and Danish TEMPRESS temperature transmitter which has the functions of high temperature alarm, low temperature refluence and CIP automatic cleaning.
Other components besides the USA LOWARA hot water pump, such as control valve, meter and fittings, all employ the first-rate domestic equipments, ensuring that the productions line control is accurate and stable and the output materials meet the requirements of the technological parameters.
